Gracie
Grazer 25

The Gracie Grazer Series is an award-winning and patented LED strip system with built-in lens optics offering ultimate control for wall grazing. Various mounting accessories and the ability to bend in two axes makes the Grazer Series incredibly versatile. Gracie Grazer 25 is the RGBW cousin of Gracie Gracie 23 which is available in 2700K, 3000K or 4000K.

Features
  • Wall grazing optics.
  • iF Design Award.
  • Black or white outer silicon casing.
  • RGBW LEDs.
Additional Information
  • Customised lengths and configurations, made to measure.
  • Installation: Interior and exterior.
  • Material: Silicon casing, plastic optics.
  • Power supply: 24V DC - remote driver options ranging from 6W up to 320W.
  • Dimming: Various options available including Casambi, DALI, 0-10V, DMX – please enquire.
Mounting Options
  • Ceiling mounted
Diffuser Options
  • 25° wall grazing optic
Profile Finish Options
  • Natural silver anodised
    $item['profile_finish_option']
  • Textured White powder coat
    $item['profile_finish_option']
  • Textured Black powder coat
    $item['profile_finish_option']
  • Custom powder coat colours
    $item['profile_finish_option']

LED Options

Other LED strip options including other optics may be available upon request. Please consult your local distributor for further information.

Gracie Grazer 25
Code
Watts per metre
Colour temp.
Lumens per metre
LEDs per metre
Cutting increments
Beam
Max. length per feed
Protection
GG25-25-RGBW-WH
GG25-25-RGBW-BL
25W
RGBW
1220
1080
24
250mm
25°
5M
IP65
Wattage and lumen tolerance +/- 10% . Colour temperature tolerance +/- 5%.

Joining and Mounting Accessories

Mounting clip

GG25-MC

Aluminium mounting profile

GG25-MP

Adjustable mounting bracket (for aluminium mounting profile) GG25

GG25-MBADJ

End cap

GG25-EC-WH (white) / GG25-EC-BL (black)

Connector cable

GG25-CC-WH (white) / GG25-CC-BL (black)

End cap with feed & connector, side feed or top feed

GG25-TF-WH (white, top feed) / GG25-TF-BL (black, top feed) / GG25-SF-WH (white, side feed) / GG25-SF-1-BL (black, side feed)

Specification Sheet
