Wall Luminaire

Shielded wall luminaires with symmetrical or asymmetrical light distribution, which are particularly suitable for installation on pillars and front surfaces of walls, thanks to their compact dimensions.
With our LED technology, we are continuing the design idea of the previous successful luminaires. Compact, efficient and ideally equipped for long and economical operating times – these luminaires embody the consistent implementation of LED technology.
For different installation heights and many different uses in private and public areas.
Part of BEGA's "Dark Sky" series as they direct their light with high efficiency onto the illuminated area, and emit less than 1% of their luminous flux into the upper half-space of the luminaire.

Applications

For decorative, accentuating lighting solutions in outdoor areas, for building access areas, facades.

Luminaire Type

Wall Lights, Dark Sky

Installation

Exterior

Finishes

Silver | Graphite

Colour Temperature

3000K | 4000K

Material

Cast aluminium, aluminium and stainless steel | BEGA Unidure ® coating technology | Safety glass | Reflector surface made of pure aluminium

Mounting Options

Wall Surface Mounted

IK Rating

IK06

CRI

>90

Symmetrical Light Distribution

Variation
System Power
Lumens
Control
Beam Angle
IP
Dimensions

33814

9.7W

787lm

DALI

IP64

W 110mm x H 190mm x D 110mm

33816

16.5W

1729lm

DALI

IP64

W 130mm x H 230mm x H 135mm

Asymmetrical Light Distribution

Variation
System Power
Lumens
Control
Beam Angle
IP
Dimensions

33815

9.5W

628lm

DALI

IP64

W 110mm x H 190mm x D 110mm

33817

16.5W

1389lm

DALI

IP64

W 130mm x H 230mm x D 135mm

Product variations may be available, please enquire.
