Recessed Unshielded Light Wall Luminaire

The BEGA  recessed luminaire for walls and staircases with unshielded light provides clear, functional illumination for exterior façades, stairs and circulation zones. Its compact, flush‑mounted design integrates discreetly into architectural surfaces, while the unshielded distribution casts even light onto adjacent planes for enhanced visibility and safety. Constructed from robust cast aluminium with a BEGA Tricoat® finish and safety glass, the luminaire is rated IP65 for dependable outdoor performance. Designed for use with external on/off or DALI‑controllable power supplies and specified with a 3000 K colour temperature, it delivers consistent, high‑quality illumination with refined architectural presence.

Backed by BEGA’s 20‑year availability guarantee for replacement parts and LED modules, it ensures long‑term support and durability.

Applications

Staircase, Walkways, Corridors

Luminaire Type

Wall Lights

Installation

Exterior

Finishes

Silver | Graphite

Colour Temperature

3000K | 4000K

Material

Cast aluminium | Safety glass

Mounting Options

Wall Recessed

IK Rating

IK05

CRI

>80

Unshielded Light

Variation
System Power
Lumens
Control
Beam Angle
IP
Dimensions

33109

4.8W

360lm

Non Dim

IP65

W 170mm x H 70mm x D 65mm

33165

6.8W

566lm

Non Dim

IP65

W 260mm x H 70mm x D 65mm

33168

818W

939lm

Non Dim

IP65

W 320mm x H 70mm x D 65mm

33155

14.0W

1160lm

DALI

IP65

W 330mm x H 125mm x D 90mm

33157

18.0W

1602lm

DALI

IP65

W 420mm x H 125mm x D 90mm

33159

22.5W

2036lm

DALI

IP65

W 520mm x H 125mm x D 90mm

Location Luminaires

Variation
System Power
Lumens
Control
Beam Angle
IP
Dimensions

33107

2.5W

187lm

Non Dim

IP65

W 170mm x H 70mm x D 65mm

33163

3.8W

264lm

Non Dim

IP65

W 260mm x H 70mm x D 65mm

33166

4.8W

422lm

Non Dim

IP65

W 320mm x H 70mm x D 65mm

33154

6.8W

609lm

Non Dim

IP65

W 330mm x H 125mm x D 90mm

33156

8.8W

841lm

Non Dim

IP65

W 420mm x H 125mm x D 90mm

33158

10.9W

1084lm

Non Dim

IP65

W 520mm x H 125mm x D 90mm

Product variations may be available, please enquire.
